- Resistance against corrosion, distortion and other harmful effects of the environment.
- Easy maintenance and operation.
- A variety of design options, wide range of colours.
- Windows can be made in very big sizes, any shape and with different ways of opening.
- Efficient thermal and sound insulation.
Technical information
| RANGES | SCHÜCO AWS 75.SI | SCHÜCO AWS 70.HI | SCHÜCO AWS 65 |
|---|---|---|---|
| Outstanding thermal insulation windows | New design basic series windows with good thermal insulation | Versatile basic series for creative design | |
| Basic depth of the frame | 75 mm | 70 mm | 65 mm |
| Basic depth of the vent frame | 85 mm | 80 mm | 75 mm |
| Thickness of blank glazing | 19 – 55 mm | 11 – 52 mm | 4 – 45 mm |
| Thickness of vent glazing | 19 – 65 mm | 21 – 62 mm | 11 – 55 mm |
| Thermal insulation per DIN EN ISO 10077-2 |
Uf = 0,9 – 1,6 W/m²K | Uf = 1,5 – 1,9 W/m²K | Uf = 1,9 – 2,4 W/m²K |
| Sound insulation per DIN EN ISO 140-3 for |
Rw 48 dB | Rw 48 dB | Rw 47 dB |
| Burglar-resistance per DIN V ENV 1627 to 1630 |
WK3 | WK3 | WK3 |
| Air permeability per DIN EN 12207 |
Class 4 | Class 4 | Class 4 |
| Weathertightness per DIN EN 12208 |
Class 9a | Class 9a | Class 9a |
| Resistance to wind-load per DIN EN12210* |
Class C5/B5 | Class C5/B5 | Class C5/B5 |
| Mechanical load per DIN EN 13115 |
Class 4 | Class 4 | Class 4 |
| Durability per DIN EN 12400 |
Class 3 | Class 3 | Class 3 |
